ENTHRONE 29

29"Offset Printing Press

Concept

High quality in a compact design — the perfect answer for today’s opportunities

The Enthrone embodies the high print quality and leading-edge technologies that have become synonymous with Komori. And with its stepless operator-side design and small footprint, the Enthrone fits easily in any installation space.
The highly specified Enthrone is configured with double-size impression and transfer cylinders to ensure consistent performance on short runs of a diverse work mix.

Accommodating sheet thicknesses of 0.04 mm to 0.6 mm, the press dramatically shortens the time required for changeover between light and heavy stocks because no transfer cylinder gripper pad adjustment is necessary. The Enthrone, in short, enables working efficiencies that result in higher margins and business growth.

Read More

Features

  • Embodies high print quality and leading-edge technologies in a press offering full basic functions. With stepless operator-side design and small footprint, the Enthrone fits easily in any installation space.
  • Employs an array of double-size impression and transfer cylinders to ensure consistent performance on short runs of a diverse work mix.
  • Handles sheet thicknesses of 0.04 mm to 0.6 mm.
  • Time required for changeover between light and heavy stocks is dramatically shortened because no transfer cylinder gripper pad adjustment is necessary.
Model ENTHRONE 26 ENTHRONE 29
Number of colors 2,4,5 2,4,5
Max. sheet size mm 480×660 530×750
Max. printing area mm 470×650 520×740
Plate size mm 560×670 605×760
Feeder pile height mm 800 800
Delivery pile height mm 600 600

* Performance and numbers may differ from specifications herein. Specifications may also be modified for product improvements.
