MBO B30E
B1 size Buckle Folder
Concept
Folder with high folding precision due to high operating speed and robust construction
The MBO B30E presents itself efficiently and with good quality results – perfect for standard production. With additional or alternative equipment features, the quality, performance and process stability of your buckle folding machine may even be further extended.
Features
- High efficiency thanks to an attractive cost/performance ratio
- Well-proven MBO components for constant quality and long lifetime
- Simple construction for optimal operability
- Low maintenance
| model |
MBO B30E |
|
|---|---|---|
| Max. sheet size | mm |
Pile feeder：760x1,200 Palletized feeder：760x1,200 |
| Min. sheet size | mm |
Pile feeder ：150x200 Palletized feeder：170x250 |
| Sheet thickness (weight) | gms | 35～250 |
| Speed | m/min | 205 |
|
Number of buckles |
plates | 4 or 6 |
| Available configurations |
Second unit for parallel folding(4 or 6 plates) Third unit for parallel folding(4 plates) |
* Performance and numbers may differ from specifications herein, and specifications may also be modified for product improvements.
