MBO B30E

B1 size Buckle Folder

Concept

Folder with high folding precision due to high operating speed and robust construction

The MBO B30E presents itself efficiently and with good quality results – perfect for standard production. With additional or alternative equipment features, the quality, performance and process stability of your buckle folding machine may even be further extended.

The MBO B30E is the solution for high (standard) print runs and rare changeover – ideally suited for enterprises processing jobs with more or less identical folding types.

Read More

Features

  • High efficiency thanks to an attractive cost/performance ratio
  • Well-proven MBO components for constant quality and long lifetime
  • Simple construction for optimal operability
  • Low maintenance


model

MBO B30E

Max. sheet size mm

Pile feeder:760x1,200

Palletized feeder:760x1,200
Continuous feeder:760x1,250

Min. sheet size mm

Pile feeder :150x200

Palletized feeder:170x250
Continuous feeder:150x180

Sheet thickness (weight) gms 35~250
Speed m/min 205

Number of buckles

plates 4 or 6
Available configurations

Second unit for parallel folding(4 or 6 plates)

Third unit for parallel folding(4 plates)

    * Performance and numbers may differ from specifications herein, and specifications may also be modified for product improvements.
